Cảm biến áp suất Danfoss MBS 3000-1811-A0AB04-0
Lượt xem:
377
Mã sản phẩm:
060G1930
Giá:
3.000.000 VNĐ
Thương hiệu:
DANFOSS
Xuất xứ:
TRUNG QUỐC
- Thông tin sản phẩm
- Bình luận
THÔNG SỐ KỸ THUẬT
| + supply | Pin 1 |
| – common | Pin 2 |
| Accuracy, max. +/- FS [%] | 1 % |
| Accuracy, typical +/- FS [%] | 0.5 % |
| Adj. zero point and span | No |
| Ambient temperature range [°C] [Max] | 85 °C |
| Ambient temperature range [°C] [Min] | -40 °C |
| Ambient temperature range [°F] [Max] | 185 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
| Approval | ATEX |
| Approval comments | ATEX Ex nA IIA T3 Gc |
| Compensated temp. range [°C] [Max] | 80 °C |
| Compensated temp. range [°C] [Min] | 0 °C |
| Compensated temp. range [°F] [Max] | 176 °F |
| Compensated temp. range [°F] [Min] | 32 °F |
| Electrical conn. Male/Female – C/N: 060G6467 | Male |
| Electrical connection | DIN-plug |
| Electrical connection size | 4 pin |
| Electrical connection standard | EN 175301-803-A |
| Enclosure rating IP | IP65 |
| Flush diaphragm | No |
| High Clipping Level | 22.4 |
| International Article Number | 5702428931854 |
| Intrinsically safe | No |
| Low Clipping Level | 3.6 |
| Medium temperature range [°C] [Max] | 85 °C |
| Medium temperature range [°C] [Min] | -40 °C |
| Medium temperature range [°F] [Max] | 185 °F |
| Medium temperature range [°F] [Min] | -40 °F |
| Non-linearity BFSL ±FS [%] | 0.5 % |
| Output signal | Current |
| Output signal [mA] [Max] | 20 mA |
| Output signal [mA] [Min] | 4 mA |
| Overload pressure max. [bar] | 1.8 bar |
| Overload pressure max. [psi] | 26 psi |
| Packing format – C/N: 060G6467 | Multi pack |
| Pressure connection HEX [mm] | 27 mm |
| Pressure connection size | 1/4 |
| Pressure connection standard | EN 837 |
| Pressure connection type | G |
| Pressure Male/Female | Male |
| Pressure range [bar] [Max] | 0.3 bar |
| Pressure range [bar] [Min] | 0 bar |
| Pressure range [psi] [Max] | 4.35 psi |
| Pressure range [psi] [Min] | 0 psi |
| Pressure unit reference | Gauge (relative) |
| Product Group | Sensors |
| Product name | Pressure transmitter |
| Pulse-snubber | No |
| Quantity per packing format | 20 pc |
| Response time max. [ms] | 4 ms |
| RsExtrapolateMissingPressure | 0=Standard |
| Specification key – C/N: 060G6467 | MBS 3000-DE11-A0AB04-0 |
| Supply voltage [V] DC [Max] | 32 V |
| Supply voltage [V] DC [Min] | 9 V |
| Type | MBS 3000 |
